Plenum MTP Elite Fiber Cables

Plenum MTP Elite Fiber Cables

MTP FiberShield Specifications

When designing complex fiber optic networks, often multi-fiber cables are utilized in order to minimize cost and maximize efficiency. While the MPO connector has long been the optimal choice when running multi-fiber installations, OptoSpan has opted to incorporate the higher performing variant known as the MTP Elite® connector designed by U.S. Conec.

Need Help? Get Answers from an MTP/MPO Experts

The MTP Elite® fiber cable connector is an improved MPO connector, introducing mechanical redesigns in order to maintain a secure physical connection with devices and strict manufacturing tolerances in order to surpass the standard MTP® connector by reducing the amount of signal loss.

All 8, 12 and 24 fiber MTP Elite cables feature OptoSpan’s new and exclusive FiberShield design. The FiberShield design uses three times the PVC jacket and DuPont Kevlar to protect the delicate optical fibers located inside the cables, resulting in a flexible yet robust 4.5mm cable that is 5x stronger than the standard 3.0mm cable.

The standard MTP® fiber cable design has improved the original MPO fiber cable in areas including the floating ferrule in order to maintain a secure connection, rounded metal pins to prevent damage to mating adapters, internal recessed metal pin clamp to prevent pin breakage, and an oval shaped internal spring to avoid fiber damage. The MTP Elite® fiber cable maintains stricter tolerances in the manufacturing process, allowing for even less signal loss when mating physical devices or cables, while remaining completely compatible with MPO and standard MTP® connectors and networking devices.

8 Fiber Plenum MTP Elite

8 Fiber Plenum MTP Elite

12 Fiber  MTP Elite

12 Fiber Plenum MTP Elite

24 Fiber Plenum MTP Elite

24 Fiber Plenum MTP Elite

48 Fiber Plenum MTP Elite

48 Fiber Plenum MTP Elite

72 Fiber Plenum MTP Elite

72 Fiber Plenum MTP Elite

96 Fiber Plenum MTP Elite

96 Fiber Plenum MTP Elite

144 Fiber Plenum MTP Elite

144 Fiber Plenum MTP Elite

The Plenum line of MTP Elite® fiber cables is intended to meet certain building regulations for fire resistant cabling. Best installed in areas which may not be suitable for standard fiber optic cables such as the inner walls or ceilings of a building, the Plenum material is fire-retardant and allows for less smoke to be produced in the unfortunate case of a fire. In cases which fiber cabling need only be installed along outer floors or outside of buildings, standard riser jackets or armored jackets may be a more appropriate solution.

For additional information, view our other MTP Elite Fiber Cables pages such as MTP Elite Cables, MTP Elite Breakout Cables, or Plenum MTP Elite Breakout Cables.
